Radionuclide Dosimetric Data Sheets
Iridium-193m
Summary data
General
Classification
Isotope: Ir-193m
Atomic number (Z): 77
Mass number (A): 193
Neutron number (N): 116
Radioactive decay
Decay modes: Internal transition
Half-life: 10.53 [d]
Decay constant: 7.6187e-07 [1/s]
Daughters: Ir-193 (100.0%)
Radioactive daughters: None
Dosimetric constants
Mean alpha energy: 0.0 [MeV]
Mean electron energy: 0.0776 [MeV]
Mean photon energy: 0.00266 [MeV]
Air kerma rate constant, Γ10: 2.530e-18 [Gy·m2/Bq·s]
Air kerma coefficient, Kair: 2.530e-18 [Gy·m2/Bq·s]
Equilibrium dose constant for weakly-penetrating radiations (α and/or
electrons), Δwp: 1.243e-14 [Gy·kg/Bq·s]
Equilibrium dose constant for alphas, Δα: 0.000e+00
[Gy·kg/Bq·s]
Equilibrium dose constant for betas/electrons, Δβ-,β+,e-:
1.243e-14 [Gy·kg/Bq·s]
Equilibrium dose constant for photons, Δp: 4.262e-16
[Gy·kg/Bq·s]
Dose point kernels (plot)
Dose point kernel source: Graves, et al. Medical Physics. 2019 Nov.; 46(11):5284-5293.
Note: Bins are spaced every 0.1 mm until a radius of 10 cm, and every 1 mm until a radius of 2 m.
Download tabulated dose point kernel file here: www.mirdsoft.org/products/MIRDspecs/Ir-193m DPK.csv
Summary spectra (plot)
Spectra source: ICRP Publication 107: Nuclear Decay Data for Dosimetric Calculations. Ann. ICRP 2008, 38 (3).
Download tabulated summary spectra file here: www.mirdsoft.org/products/MIRDspecs/Ir-193m Summary Spectrum.csv
Tabulated data
Summary spectra (table)
Spectra source: ICRP Publication 107: Nuclear Decay Data for Dosimetric Calculations. Ann. ICRP 2008, 38 (3).
Note: Radiations with yield < 0.01 are excluded from the table, but are available in the linked *.csv data.
Download tabulated summary spectra file here: www.mirdsoft.org/products/MIRDspecs/Ir-193m Summary Spectrum.csv
|
Energy [MeV] |
Yield [#/nt] if > 0.01 |
Radiation type |
|
4.53478e-05 |
7.097e+00 |
X-ray |
|
1.98857e-03 |
3.340e-02 |
X-ray |
|
9.09081e-03 |
1.497e-02 |
X-ray |
|
9.16921e-03 |
1.320e-01 |
X-ray |
|
1.09194e-02 |
2.416e-02 |
X-ray |
|
3.54639e-05 |
1.356e+00 |
Auger electron |
|
1.69955e-04 |
2.337e+00 |
Auger electron |
|
3.31780e-04 |
4.765e-01 |
Auger electron |
|
3.52627e-04 |
9.986e-02 |
Auger electron |
|
5.27527e-04 |
1.015e-01 |
Auger electron |
|
1.63659e-03 |
1.141e+00 |
Auger electron |
|
1.83563e-03 |
1.009e-01 |
Auger electron |
|
6.75236e-03 |
3.328e-01 |
Auger electron |
|
8.70243e-03 |
1.338e-01 |
Auger electron |
|
1.06723e-02 |
1.319e-02 |
Auger electron |
|
6.68240e-02 |
1.252e-01 |
Conversion electron |
|
6.73610e-02 |
2.228e-02 |
Conversion electron |
|
6.90060e-02 |
5.352e-01 |
Conversion electron |
|
7.76810e-02 |
2.395e-01 |
Conversion electron |
|
8.02200e-02 |
7.319e-02 |
Conversion electron |
Useful Links
Isotope decay characteristics are periodically updated as better measurements can be made - changes that may not be reflected on this page. Please see useful links:
National Nuclear Data Center (NNDC): https://www.nndc.bnl.gov/nudat3/mird/
International Atomic Energy Agency (IAEA) Livechart: https://www-nds.iaea.org/relnsd/vcharthtml/VChartHTML.html
Reference Links
ICRP Report 107: https://www.icrp.org/publication.asp?id=ICRP%20Publication%20107
Graves et al. Dose Point Kernels: https://doi.org/10.1002/mp.13789
MIRD Decay Schemes 2nd Edition: https://sites.snmmi.org/SNMMI-MAIN/iCore/Store/StoreLayouts/Item_Detail.aspx?iProductCode=0-932004-80-6
