Radionuclide Dosimetric Data Sheets
Hafnium-178m
Summary data
General
Classification
Isotope: Hf-178m
Atomic number (Z): 72
Mass number (A): 178
Neutron number (N): 106
Radioactive decay
Decay modes: Internal transition
Half-life: 31.0 [y]
Decay constant: 7.0855e-10 [1/s]
Daughters: Hf-178 (100.0%)
Radioactive daughters: None
Dosimetric constants
Mean alpha energy: 0.0 [MeV]
Mean electron energy: 0.21132 [MeV]
Mean photon energy: 2.23831 [MeV]
Air kerma rate constant, Γ10: 8.456e-17 [Gy·m2/Bq·s]
Air kerma coefficient, Kair: 8.456e-17 [Gy·m2/Bq·s]
Equilibrium dose constant for weakly-penetrating radiations (α and/or
electrons), Δwp: 3.386e-14 [Gy·kg/Bq·s]
Equilibrium dose constant for alphas, Δα: 0.000e+00
[Gy·kg/Bq·s]
Equilibrium dose constant for betas/electrons, Δβ-,β+,e-:
3.386e-14 [Gy·kg/Bq·s]
Equilibrium dose constant for photons, Δp: 3.586e-13
[Gy·kg/Bq·s]
Summary spectra (plot)
Spectra source: ICRP Publication 107: Nuclear Decay Data for Dosimetric Calculations. Ann. ICRP 2008, 38 (3).
Download tabulated summary spectra file here: www.mirdsoft.org/products/MIRDspecs/Hf-178m Summary Spectrum.csv
Tabulated data
Summary spectra (table)
Spectra source: ICRP Publication 107: Nuclear Decay Data for Dosimetric Calculations. Ann. ICRP 2008, 38 (3).
Note: Radiations with yield < 0.01 are excluded from the table, but are available in the linked *.csv data.
Download tabulated summary spectra file here: www.mirdsoft.org/products/MIRDspecs/Hf-178m Summary Spectrum.csv
|
Energy [MeV] |
Yield [#/nt] if > 0.01 |
Radiation type |
|
1.94278e-05 |
2.162e+01 |
X-ray |
|
1.63887e-03 |
6.556e-02 |
X-ray |
|
6.98230e-03 |
1.489e-02 |
X-ray |
|
7.83281e-03 |
2.464e-02 |
X-ray |
|
7.88959e-03 |
2.175e-01 |
X-ray |
|
9.03751e-03 |
1.808e-01 |
X-ray |
|
9.34358e-03 |
3.779e-02 |
X-ray |
|
1.05374e-02 |
3.289e-02 |
X-ray |
|
5.47191e-02 |
2.251e-01 |
X-ray |
|
5.59237e-02 |
3.939e-01 |
X-ray |
|
6.31238e-02 |
4.193e-02 |
X-ray |
|
6.33831e-02 |
8.104e-02 |
X-ray |
|
6.51063e-02 |
1.825e-02 |
X-ray |
|
8.88620e-02 |
6.436e-01 |
Gamma |
|
9.31850e-02 |
1.722e-01 |
Gamma |
|
2.13434e-01 |
8.140e-01 |
Gamma |
|
2.16668e-01 |
6.465e-01 |
Gamma |
|
2.37431e-01 |
9.316e-02 |
Gamma |
|
2.57646e-01 |
1.675e-01 |
Gamma |
|
2.77403e-01 |
1.383e-02 |
Gamma |
|
2.96812e-01 |
9.692e-02 |
Gamma |
|
3.25557e-01 |
9.410e-01 |
Gamma |
|
4.26360e-01 |
9.702e-01 |
Gamma |
|
4.54050e-01 |
1.666e-01 |
Gamma |
|
4.95013e-01 |
7.133e-01 |
Gamma |
|
5.35036e-01 |
9.410e-02 |
Gamma |
|
5.74215e-01 |
8.789e-01 |
Gamma |
|
1.07323e-05 |
1.875e+00 |
Auger electron |
|
2.44605e-05 |
2.664e+00 |
Auger electron |
|
1.59932e-04 |
7.543e+00 |
Auger electron |
|
2.81377e-04 |
2.366e-01 |
Auger electron |
|
3.03245e-04 |
1.278e+00 |
Auger electron |
|
7.24403e-04 |
2.014e-01 |
Auger electron |
|
1.36609e-03 |
3.284e+00 |
Auger electron |
|
1.54545e-03 |
1.736e-01 |
Auger electron |
|
1.76787e-03 |
1.084e-02 |
Auger electron |
|
1.93700e-03 |
2.672e-01 |
Conversion electron |
|
3.14170e-03 |
3.806e-01 |
Conversion electron |
|
6.17769e-03 |
1.039e+00 |
Auger electron |
|
7.79627e-03 |
3.855e-01 |
Auger electron |
|
9.44430e-03 |
3.605e-02 |
Auger electron |
|
1.06010e-02 |
2.723e-01 |
Conversion electron |
|
1.27000e-02 |
7.626e-02 |
Conversion electron |
|
2.33800e-02 |
2.567e-01 |
Conversion electron |
|
2.77030e-02 |
1.888e-01 |
Conversion electron |
|
4.45281e-02 |
2.496e-02 |
Auger electron |
|
5.31026e-02 |
1.292e-02 |
Auger electron |
|
7.76170e-02 |
2.683e-02 |
Conversion electron |
|
8.19400e-02 |
1.925e-02 |
Conversion electron |
|
8.24220e-02 |
2.369e-01 |
Conversion electron |
|
8.36267e-02 |
2.229e-01 |
Conversion electron |
|
8.67630e-02 |
1.025e-02 |
Conversion electron |
|
9.10860e-02 |
1.199e-01 |
Conversion electron |
|
9.31850e-02 |
3.250e-02 |
Conversion electron |
|
1.47952e-01 |
1.133e-01 |
Conversion electron |
|
1.51186e-01 |
1.319e-01 |
Conversion electron |
|
1.71949e-01 |
1.504e-02 |
Conversion electron |
|
1.92164e-01 |
1.525e-02 |
Conversion electron |
|
2.02189e-01 |
1.293e-02 |
Conversion electron |
|
2.02671e-01 |
2.674e-02 |
Conversion electron |
|
2.03876e-01 |
1.862e-02 |
Conversion electron |
|
2.05423e-01 |
1.693e-02 |
Conversion electron |
|
2.05905e-01 |
1.527e-02 |
Conversion electron |
|
2.07110e-01 |
1.010e-02 |
Conversion electron |
|
2.11335e-01 |
1.430e-02 |
Conversion electron |
|
2.14569e-01 |
1.018e-02 |
Conversion electron |
|
2.60075e-01 |
4.172e-02 |
Conversion electron |
|
3.60878e-01 |
2.152e-02 |
Conversion electron |
|
4.29531e-01 |
1.102e-02 |
Conversion electron |
Useful Links
Isotope decay characteristics are periodically updated as better measurements can be made - changes that may not be reflected on this page. Please see useful links:
National Nuclear Data Center (NNDC): https://www.nndc.bnl.gov/nudat3/mird/
International Atomic Energy Agency (IAEA) Livechart: https://www-nds.iaea.org/relnsd/vcharthtml/VChartHTML.html
Reference Links
ICRP Report 107: https://www.icrp.org/publication.asp?id=ICRP%20Publication%20107
Graves et al. Dose Point Kernels: https://doi.org/10.1002/mp.13789
MIRD Decay Schemes 2nd Edition: https://sites.snmmi.org/SNMMI-MAIN/iCore/Store/StoreLayouts/Item_Detail.aspx?iProductCode=0-932004-80-6
